RAYMAX's metal sheet fiber laser stands out on precise cutting of complex, intricate contours.Perfect industrial design is more in line with man-machine engineering.The machine is affordable and tailored for sheet metal processing enterprises. It works great with CS, SS, MS, aluminum, brass, copper, bronze, gold, silver, titanium alloy, galvanized plates, etc.
Fitur
● Configuration--Stand-alone electrical cabinet, wireless remote control.
● Low consumption--The power is more than 30% lower than the ordinary cutting machine.
● Environment friendly--Laser cutting will not create any gases for the special cutting technology for steel sheet.
● Maintenance-free--For the fiber laser cutter, the reflect lens is not needed. It will help to save a lot of time when the optical path is adjusted. The laser generator with a longer life which no need maintenance during usage, stable performance.
Parameter Mesin
| Model peralatan | MT-L1530F / MT-L2040F / MT-L2560F |
| Jenis laser | Laser serat |
| Kekuatan laser | 1000W-30000W optional |
| Rentang pemotongan yang efektif | 1500*3000mm/2000*4000mm/2500*6000mm optional |
| Akurasi reposisi | 0,02mm |
| Panjang gelombang laser | 1080±5nm |
| Sumber laser | Raycus/IPG/MAX |
| Kepala pemotongan laser | Raytools/Ospir/Precitec |
| Sistem pengaturan | Siprus |
| Peredam | Jepang Shimpo |
| Sistem penggerak | FUJI / YASKAWA |
| Elemen pneumatik | SMC Jepang |
| Bagian listrik | American Honeywell |
| Rel pemandu | Rel panduan persegi Taiwan |
| Sistem pendingin | Pendingin air pengontrol suhu konstan |
| Sistem meminyaki | Sistem meminyaki otomatis |
| kebutuhan listrik | 3 Phases 380V±10% 50HZ/60HZ |
Detail Mesin
Free your hands with auto focus laser head
Auto focus laser head cuts half of your focusing time by automatically adjusting the focus to a suitable position. You even profitmore from piercing thick plates.
Raycus laser source
Free maintenance;High electro-optical conversion efficiency (up to 25-30%), excellent beam quality, high energy density, and reliability, a wide modulation frequency; Low energy consumption, only 20%-30% of the traditional machine.
Intuitive operation system with touch control
Integrating CAD, Nest and CAM modules in one, from drawing, nesting to workpiece cutting, metal processing is just a few clicks away.
Partitioned smoke and dust exhaust system
Enjoy a better cutting environment with our partitioned smoke and dust exhaust system. Each suction port opens and closes independently to exhaust smoke of a particular area, considerably enhancing smoke removal efficiency.
Automatic edge seeking function
Auto-induct materials cutting edge and adjust cutting range according to their inclination angle automatically in case of any incorrect position.
Application & Sample
Favored by fabricators of sheet metal, electrical cabinet, elevator and escalator, kitchen appliance metal doors and windows, this sheet laser cutting machine effortlessly cuts stainless steel sheets, carbon steel sheets, galvanized sheets, etc.
FAQ
T: Saya tidak tahu mana yang cocok untuk saya?
A: Just tell us below information
1) Max work size:choose the most suitable model.
2) Materials and Cutting thickness: Power of laser generator.
3) Business industries: We sell a lot and give advice on this business line.
T: Jika beberapa masalah terjadi pada mesin ini selama masa garansi, apa yang harus saya lakukan?
A :We will supply free parts during the machine warranty period if the machine has some problems. While we also supply free life long after-sales service. So any doubts, just let us know, we will give you solutions.
T: Berapa lama waktu pengiriman Anda?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according toquantity.
Q: Do you have a CE document and other documents for customs clearance?
A: Yes, we have Original. At first we will show you and after shipment we will give you CE / Packing list / Commercial Invoice / Sales contract for customs clearance.
rincian
- Aplikasi: PEMOTONGAN LASER
- Bahan yang Berlaku: Logam
- Kondisi: Baru
- Jenis Laser: Laser Serat
- Area Pemotongan: 3000 * 1500mm
- Kecepatan Pemotongan: 140m / mnt
- Graphic Format Supported: AI, BMP, Dwg, DXP
- Ketebalan Pemotongan: 0-20mm
- CNC atau Tidak: Ya
- Mode Pendinginan: PENDINGINAN AIR
- Perangkat Lunak Kontrol: Cypcut
- Merek Sumber Laser: IPG/MAX
- Merek Kepala Laser: Raytools
- Merek Motor Servo: Yaskawa
- Merek Guiderail: PMI
- Merek Sistem Kontrol: Cypcut
- Weight (KG): 2100 KG
- Key Selling Points: Remote Control
- Garansi: 2 tahun
- Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Printing Shops, Construction works , Energy & Mining, Other, Advertising Company, industry
- Laporan Uji Mesin: Disediakan
- Inspeksi keluar video: Disediakan
- Garansi komponen inti: 2 tahun
- Komponen Inti: Sumber laser
- Mode Operasi: gelombang terus menerus
- Configuration: 5-axis
- Produk yang ditangani: Lembaran Logam
- Fitur: Dapat Diprogram
- Laser type: Fiber laser
- Rated output power: 1000w-30000w optional
- Effective cutting range: 1500*3000mm
- Reposition accuracy: 0.02mm
- Laser wavelength: 1080±5nm
- Sumber laser: Raycus
- Laser cutting head: Raytools
- Sistem kontrol: Cypcut
- Oiling system: Automatic oiling system
- Electrical requirement: 3 Phases 380V±10% 50HZ/60HZ
